Good points
- Brand: Ruck
- AC motor
- Standard temperature
- Frequency controlled
Axial 630 mm Duct Fan – AL 630 D84U 02 CFG
The AL 630 D84U 02 CFG from Ruck is an innovative and highly efficient axial fan, designed for medium pressure applications. Thanks to the application of the latest numerical design techniques, system efficiency has been improved and the operating range has been expanded. The adjustable blades make this fan suitable for various applications in both commercial buildings and industrial environments.
Optimized Design for Versatility
This fan features a lightweight and robust design, significantly simplifying installation and handling. It is equipped with an IE3 motor that is 2-stage adjustable via a Dahlander switch, allowing for energy-efficient and flexible operation. The aerodynamically optimized blades contribute to higher airflow and improved efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C. Delivered without a terminal box, but with a cable for easy connection to an external switch.
Reliable Performance from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of axial fans. With years of experience and a focus on innovation, energy efficiency, and reliable performance, all products comply with the latest ERP (Energy Related Product) guidelines and are designed for long-lasting performance, even in the most demanding applications.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320988 |
| Manufacturer's item number | AL 630 D84U 02 CFG |
| Article number | 65170121 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 18055 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 630 mm |
