- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 560 mm Duct Fan Flue Gas F400 – AL 560 D4 F4 04 CFG
The AL 560 D4 F4 04 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, specifically for flue gas discharge in accordance with the F400 standard. Thanks to the latest numerical design techniques, system efficiency has been optimized and the operating range expanded. This fan is ideal for both regular ventilation and smoke and heat extraction in case of fire (dual-use), thanks to its adjustable blades.
Efficient Design for Versatile Use
This fan features a lightweight and optimized design that facilitates installation and handling. It is equipped with an IEC standard motor suitable for frequency control, allowing you to efficiently tailor the fan to your specific requirements. The aerodynamically optimized blades contribute to efficient airflow and higher performance. This model is suitable for continuous operation at air temperatures up to 60 °C and fully complies with the F400 standard for flue gas ventilation. Delivered without a terminal box, but with a cable for easy connection to an external switch.
Durability and Reliability from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer known worldwide for its reliable, durable, and energy-efficient ventilation technologies. All products are developed in accordance with current ERP (Energy Related Product) guidelines, ensuring long-lasting performance and energy efficiency in the most demanding environments.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321909 |
| Manufacturer's item number | AL 560 D4 F4 04 CFG |
| Article number | 65170744 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 21000 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 560 mm |
