Axial 560 mm Duct Fan Flue Gas F300 – AL 560 D84U F3 01 CFG
The AL 560 D84U F3 01 CFG from Ruck is an innovative and high-efficiency axial fan, designed for flue gas extraction and daily ventilation. Thanks to the application of the latest numerical calculation methods, this model is optimized for maximum system efficiency. The adjustable blade positions provide a wide operating range, making this fan suitable for various applications. This model is F300 certified and suitable for continuous use up to 60 °C. Thus, it is perfectly applicable as a dual-use solution: for both regular air exchange and flue gas heat extraction in case of fire.
Robust Design with Optimized Weight
The AL 560 D84U F3 01 CFG features a robust yet lightweight construction, making installation and maintenance easier. The design focuses on weight reduction without compromising performance or durability. The fan is equipped with an IE3 motor that can be controlled in two speed stages via a Dahlander connection. This efficient drive allows for flexible and energy-saving operation. The specially shaped rotor and stator blades ensure high efficiency in medium pressure applications. Due to its compact size, this model is ideal for applications in medium-sized installations, both commercial and industrial.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer of high-quality ventilation systems. With over 300 employees, they develop reliable and innovative solutions that meet the strictest standards for fire safety and energy efficiency. The AL 560 D84U F3 01 CFG also complies with current ERP guidelines and is designed for top performance in demanding environments.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322470 |
| Manufacturer's item number | AL 560 D84U F3 01 CFG |
| Article number | 65171143 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 17500 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 560 mm |
