Axial 560 mm Duct Fan – AL 560 D4 04 CFG
The AL 560 D4 04 CFG from Ruck is an innovative, high-efficiency axial fan, specifically designed for medium pressure applications. Thanks to the use of advanced numerical design techniques, system efficiency has been enhanced and the operating range expanded. The adjustable blades make this fan versatile for use in various ventilation systems for both commercial buildings and industrial environments.
Optimized Design for Quick Installation
This fan features a lightweight and robust construction that significantly simplifies installation and handling. Equipped with an IEC standard motor suitable for frequency control, you can easily adjust the fan to meet your specific requirements. The aerodynamically optimized blades ensure improved airflow and contribute to increased efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C and fully complies with specifications for long-term performance. Delivered without a terminal box, but with a cable for easy connection to an external switch.
Reliable Performance from Ruck
Ruck Ventilatoren GmbH is a renowned German manufacturer known for its reliable and efficient ventilation technologies. All products are developed according to the latest ERP (Energy Related Product) guidelines and are designed for sustainable and stable performance under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320698 |
| Manufacturer's item number | AL 560 D4 04 CFG |
| Article number | 65169770 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 21000 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 560 mm |
