Axial 500 mm Duct Fan Flue Gas F400 – AL 500 D42U F4 02 CFG
The AL 500 D42U F4 02 CFG from Ruck is an advanced axial fan designed for medium pressure applications, specifically developed for flue gas extraction according to the F400 standard. Thanks to the latest numerical design techniques, system efficiency has been significantly improved and the operating range expanded. The adjustable blades make this fan suitable for both standard ventilation and smoke and heat extraction in case of fire (dual-use).
Optimized for Efficient Operation
This fan features a lightweight, optimized design that facilitates installation and handling. It is equipped with an IE3 motor that is 2-stage adjustable via a Dahlander switch for flexible and energy-efficient operation. The aerodynamically optimized blades contribute to higher efficiency. This model is designed for continuous operation at air temperatures up to 60 °C and fully complies with the F400 standard. Delivered without a terminal box, but with a cable for easy connection to an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer known for its reliable and innovative products. With a strong focus on quality, energy efficiency, and sustainability, all products comply with current ERP (Energy Related Product) guidelines and deliver excellent performance under a variety of conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321831 |
| Manufacturer's item number | AL 500 D42U F4 02 CFG |
| Article number | 65170713 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 15480 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 500 mm |
