Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 500 mm Duct Fan Flue Gas F400 – AL 500 D2 F4 01 CFG
The AL 500 D2 F4 01 CFG from Ruck is a powerful and highly efficient axial fan, designed for medium pressure applications and flue gas extraction according to the F400 standard. Thanks to advanced numerical design techniques, the system efficiency has been improved and the operating range has been expanded. This fan is suitable for both regular ventilation and smoke and heat extraction in case of fire (dual-use), offering flexible deployment through adjustable blades.
Optimized Design for Ease of Use
The fan features a lightweight construction that makes installation and handling straightforward. It is equipped with an IEC standard motor suitable for frequency control, allowing you to efficiently tune the fan to your ventilation needs. The aerodynamically optimized blades contribute to efficient air displacement, resulting in higher system efficiency. This model is designed for continuous operation at air temperatures up to 60 °C and fully complies with the F400 standard. Delivered without a terminal box, but with a cable for direct connection to an external switch.
Reliable Technology from Ruck
Ruck Ventilatoren GmbH is a German manufacturer renowned worldwide for its innovative and reliable ventilation technology. All products are developed according to current ERP (Energy Related Product) guidelines and are built for durability and excellent performance in the most demanding applications.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321824 |
| Manufacturer's item number | AL 500 D2 F4 01 CFG |
| Article number | 65170709 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 19810 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 500 mm |
