Axial 500 mm Duct Fan Flue Gas F300 – AL 500 D2 F3 03 CFG
The AL 500 D2 F3 03 CFG from Ruck is an innovative and high-efficiency axial fan, specifically developed for flue gas extraction and daily ventilation. Utilizing the latest numerical calculation methods, this model is optimized for maximum system efficiency. With various adjustable blade positions, the fan offers a wide operating range, making it suitable for diverse applications. This fan is certified as an F300 flue gas fan and designed for continuous use up to 60 °C. Thus, it is an ideal solution for both regular air exchange and smoke heat extraction in case of fire (dual-use).
Robust Design with Optimized Weight
The AL 500 D2 F3 03 CFG is designed with a sturdy yet lightweight construction, simplifying installation and making maintenance quicker and easier. Thanks to the optimized design, the weight has been significantly reduced without compromising performance or durability. The fan is equipped with an IEC standard motor suitable for frequency control and meets the IE3 energy efficiency class. The aerodynamically designed rotor and stator blades ensure optimal efficiency in medium-pressure applications. The AL series is available in various diameters, including this 500 mm version, and is suitable for both commercial and industrial applications.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in developing axial fans for flue gas extraction among other applications. With a team of over 300 specialists, they develop innovative ventilation solutions daily. All products meet the strictest standards in energy efficiency, fire safety, and the latest ERP guidelines. You can be assured of a quality product you can rely on, even in critical situations.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322654 |
| Manufacturer's item number | AL 500 D2 F3 03 CFG |
| Article number | 65171227 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 22430 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 500 mm |
