Good points

Brand: Ruck
AC motor
Standard temperature
Frequency controlled

Axial 500 mm Duct Fan – AL 500 D2 03 CFG

The AL 500 D2 03 CFG from Ruck is an innovative axial fan with high efficiency, designed for medium pressure applications. Thanks to advanced numerical design techniques, system efficiency has been enhanced and the operating range significantly expanded. The adjustable blades make this fan versatile for applications in commercial, industrial, and other environments where reliable air movement is required.

Practical Design for Quick Installation

The fan is lightweight and features an optimized construction for easy assembly and handling. It is equipped with an IEC standard motor suitable for frequency control, allowing you to operate the fan efficiently and flexibly. The aerodynamically shaped blades ensure improved airflow and higher energy efficiency. Suitable for continuous operation at air temperatures up to 60 °C. Delivered without a terminal box, but with a cable for quick connection to an external switch.

Quality from Ruck

Ruck Ventilatoren GmbH is a German manufacturer known for quality, reliability, and innovation. All fans are developed according to current ERP (Energy Related Product) guidelines and are built to perform under various conditions.

More Information

Brand	Ruck ventilatoren GmbH
Category	Axial duct fan
GTIN	8719544322340
Manufacturer's item number	AL 500 D2 03 CFG
Article number	65171003

Specifications

Category code	35
Length	443 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IPX4
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	22430 m³/h
Suitable for frequency control	Yes
Pole-reversible	No
Suitable for transformer control	No
Suitable for electronic control	Yes
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	500 mm
