Good points

Brand: Ruck
AC motor
Rookgas F400
Frequency controlled

Axial 450 mm Duct Fan Flue Gas F400 – AL 450 D4 F4 02 CFG

The AL 450 D4 F4 02 CFG from Ruck is an innovative and efficient axial fan designed for medium pressure applications, certified for flue gas discharge according to the F400 standard. Thanks to the latest numerical design techniques, the system efficiency has been increased and the operating range significantly expanded. The adjustable blades make this fan suitable for both daily ventilation and smoke and heat extraction in case of fire (dual-use).

Optimized Design with Smart Motor Control

This fan features a lightweight and robust construction, optimized for quick installation and easy handling. It is equipped with a powerful IE3 motor that is 2-stage adjustable via a Dahlander switching, ensuring flexible and energy-efficient control. The aerodynamically optimized blades contribute to high system efficiency. Designed for continuous operation at air temperatures up to 60 °C and fully compliant with F400 specifications. Delivered without a terminal box, but with a cable for easy connection of an external switch.

Quality You Can Rely On

Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in ventilation technology. All products are developed according to current ERP (Energy Related Product) guidelines and are known for their reliability, durability, and high performance under demanding conditions.

More Information

Brand	Ruck ventilatoren GmbH
Category	Flue Gas Axial Fan
GTIN	8719544322265
Manufacturer's item number	AL 450 D4 F4 02 CFG
Article number	65170929

Specifications

Category code	35
Length	368 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IPX4
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	10025 m³/h
Suitable for frequency control	Yes
Pole-reversible	No
Suitable for transformer control	No
Suitable for electronic control	Yes
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	450 mm
