Good points

Brand: Ruck
AC motor
Rookgas F400
Frequency controlled

Axial 450 mm Duct Fan Flue Gas F400 – AL 450 D2 F4 02 CFG

The AL 450 D2 F4 02 CFG from Ruck is an efficient and powerful axial fan, designed for medium pressure applications and suitable for flue gas discharge according to the F400 standard. Thanks to the application of the latest numerical design techniques, system efficiency has been improved and the operating range has been expanded. With adjustable blades, this fan is versatile, suitable for both daily ventilation and smoke and heat extraction in case of fire (dual-use).

Thoughtful Design for Quick Installation

This fan features a lightweight construction, optimized for fast and easy installation. Equipped with an IEC standard motor suitable for frequency control. The aerodynamically shaped blades ensure efficient air displacement and contribute to higher system efficiency. Suitable for continuous operation at air temperatures up to 60 °C and fully compliant with the F400 specification. The fan is supplied without a terminal box, but with a cable for easy connection of an external switch.

Reliable German Quality

Ruck Ventilatoren GmbH is a leading manufacturer with a strong focus on innovation, reliability, and energy efficiency. All products are developed according to current ERP (Energy Related Product) guidelines and produced according to high quality standards, ensuring you can always rely on dependable performance.

More Information

Brand	Ruck ventilatoren GmbH
Category	Flue Gas Axial Fan
GTIN	8719544322241
Manufacturer's item number	AL 450 D2 F4 02 CFG
Article number	65170923

Specifications

Category code	35
Length	368 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IPX4
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	13070 m³/h
Suitable for frequency control	Yes
Pole-reversible	No
Suitable for transformer control	No
Suitable for electronic control	Yes
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	450 mm
