Axial 450 mm Duct Fan Flue Gas F300 – AL 450 D42U F3 01 CFG
The AL 450 D42U F3 01 CFG from Ruck is a powerful, high-efficiency axial fan designed for medium pressure applications. This fan is certified according to the F300 standard and is suitable for both daily ventilation and smoke and heat extraction in case of fire (dual-use). Thanks to advanced numerical design techniques, system efficiency has been enhanced and the operating range has been significantly increased. The adjustable blades allow for flexible application in various installations.
Robust and User-Friendly Design
The fan features an optimized, lightweight construction, ensuring easy installation and efficient handling. It is equipped with an IE3 motor that can be controlled in two stages via a Dahlander switch. This means you can easily and energy-efficiently control the fan. The aerodynamically optimized blades contribute to increased efficiency. Suitable for continuous operation at air temperatures up to 60 °C. Delivered without a terminal box, but with a cable for easy connection of an external switch.
Quality You Can Trust
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in ventilation technology. All products are developed according to the latest ERP (Energy Related Product) guidelines and are known for their reliability, durability, and high performance.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322449 |
| Manufacturer's item number | AL 450 D42U F3 01 CFG |
| Article number | 65171105 |
Specifications
| Category code | 35 |
| Length | 368 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 14880 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 450 mm |
