Axial 450 mm Duct Fan Flue Gas F300 – AL 450 D42U F3 01 CFG
The AL 450 D42U F3 01 CFG from Ruck is an efficient axial fan designed for medium pressure applications and flue gas extraction, certified according to the F300 standard. Thanks to the latest numerical design techniques, system efficiency has been enhanced and the operating range significantly expanded. The adjustable blades make this fan suitable for both daily ventilation and smoke and heat extraction in case of fire (dual-use).
Robust Design with Optimized Weight
This fan features a lightweight, optimized design that ensures easy installation and efficient handling. The IE3 motor is 2-stage adjustable via a Dahlander switching, providing flexible and energy-efficient control. The aerodynamically optimized blades contribute to a higher efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C and complies with the F300 specification. The fan is supplied without a terminal box but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a German manufacturer with years of experience in ventilation technology. They are known for their reliable, energy-efficient solutions and develop all their products according to current ERP (Energy Related Product) guidelines.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322326 |
| Manufacturer's item number | AL 450 D4 F3 02 CFG |
| Article number | 65170953 |
Specifications
| Category code | 35 |
| Length | 368 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 10025 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 450 mm |
