Good points

Brand: Ruck
AC motor
Standard temperature
Frequency controlled

Axial 450 mm Duct Fan – AL 450 D2 01 CFG

The AL 450 D2 01 CFG from Ruck is an innovative axial fan with high efficiency, developed for medium pressure applications. By utilizing the latest numerical design techniques, the system efficiency has been optimized and the operating range has been broadened. Thanks to the adjustable blades, this fan is widely applicable for various uses in commercial buildings and industry.

Robust Design with Optimized Weight

This fan features a robust yet lightweight construction, making installation easier and ensuring efficient handling. It is equipped with an IEC standard motor suitable for frequency control. The aerodynamically optimized blades enhance system efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C. Delivered without a terminal box, but with a cable for easy connection to an external switch.

Quality Guaranteed

Ruck Ventilatoren GmbH is a renowned German manufacturer and market leader in axial fans. With a focus on innovation, sustainability, and performance, all products are developed according to the latest ERP (Energy Related Product) guidelines and produced to high-quality standards.

More Information

Brand	Ruck ventilatoren GmbH
Category	Axial duct fan
GTIN	8719544320865
Manufacturer's item number	AL 450 D2 01 CFG
Article number	65170060

Specifications

Category code	35
Length	368 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IP55
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	16360 m³/h
Suitable for frequency control	Yes
Suitable for transformer control	Yes
Suitable for electronic control	No
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	450 mm
