Axial 400 mm Duct Fan Flue Gas F400 – AL 400 D42U F4 02 CFG
The AL 400 D42U F4 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, specifically for flue gas extraction in accordance with the F400 standard. By utilizing the latest numerical design techniques, the system efficiency has been enhanced and the operating range significantly broadened. Thanks to the adjustable blades, this fan is perfectly suited for both daily ventilation and smoke and heat extraction during a fire (dual-use).
Robust Design with Optimized Weight
This fan features an optimized, lightweight construction for easy installation and efficient handling. Equipped with a powerful IE3 motor that is 2-stage adjustable via a Dahlander connection, it provides flexible control and energy-efficient operation. The aerodynamically optimized blades contribute to increased system efficiency. Suitable for continuous operation at air temperatures up to 60 °C and certified for flue gas extraction according to F400. The fan is supplied without a terminal box, but with a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. As a specialist in axial fans, Ruck guarantees innovation, quality, and reliability. All products are developed according to the latest ERP (Energy Related Product) requirements and are designed for maximum durability and safety.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321442 |
| Manufacturer's item number | AL 400 D42U F4 02 CFG |
| Article number | 65170392 |
Specifications
| Category code | 35 |
| Length | 368 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 6860 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 400 mm |
