Good points

Brand: Ruck
AC motor
Rookgas F300
Frequency controlled

Axial 400 mm Duct Fan Flue Gas F300 – AL 400 D42U F3 02 CFG

The AL 400 D42U F3 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, certified for flue gas discharge according to the F300 standard. By employing the latest numerical design techniques, system efficiency has been significantly enhanced and the operating range expanded. Thanks to the adjustable blades, this fan is suitable for both daily ventilation and smoke and heat extraction during a fire (dual-use).

Robust Design with Optimized Weight

This fan is designed with a lightweight, optimized construction that simplifies installation and improves handling. Equipped with an IE3 motor that is 2-stage adjustable via a Dahlander connection for energy-efficient and flexible operation. The aerodynamically optimized blades ensure increased system efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C and complies with the F300 specification for flue gas ventilation. The fan is supplied without a terminal box but includes a cable for easy connection to an external switch.

Quality Guaranteed

Ruck Ventilatoren GmbH is a leading German company with years of experience and a strong focus on innovation. As a market leader in axial fans, they guarantee quality and reliability. All products meet the latest ERP (Energy Related Product) requirements and are produced with care and precision.

More Information

Brand	Ruck ventilatoren GmbH
Category	Flue Gas Axial Fan
GTIN	8719544321497
Manufacturer's item number	AL 400 D42U F3 02 CFG
Article number	65170454

Specifications

Category code	35
Length	368 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IPX4
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	6860 m³/h
Suitable for frequency control	Yes
Pole-reversible	No
Suitable for transformer control	No
Suitable for electronic control	Yes
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	400 mm
