Axial 400 mm Duct Fan – AL 400 D4 01 CFG
The AL 400 D4 01 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. Thanks to the application of the latest numerical design techniques, system efficiency has been significantly increased and the operating range expanded. The adjustable blades provide maximum flexibility, making the fan suitable for a wide range of ventilation applications in both commercial and industrial environments.
Robust Design with Optimized Weight
This fan features a lightweight yet durable construction that ensures easy installation and efficient handling. The optimized design reduces weight without compromising strength. The fan is equipped with an IEC standard motor and is suitable for frequency control. The aerodynamically optimized blades contribute to increased system efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C. Delivered without a terminal box, but with a cable for easy connection of an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With more than 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320841 |
| Manufacturer's item number | AL 400 D4 01 CFG |
| Article number | 65170053 |
Specifications
| Category code | 35 |
| Length | 368 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 7310 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 400 mm |
