Axial 355 mm Duct Fan Flue Gas F400 – AL 355 D4 F4 01 CFG
The AL 355 D4 F4 01 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, specifically for flue gas discharge in accordance with the F400 standard. By utilizing the latest numerical design techniques, system efficiency has been enhanced and the operating range expanded. The adjustable blades make the fan versatile for both regular ventilation and smoke and heat extraction during a fire (dual-use).
Robust Design with Optimized Weight
This fan features a robust yet lightweight construction, making installation and handling straightforward. Thanks to the optimized design, the weight has been reduced without compromising durability. Equipped with an IEC standard motor suitable for frequency control. The aerodynamically optimized blades contribute to increased system efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C and meets the F400 specification for flue gas ventilation. The fan is supplied without a terminal box but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321398 |
| Manufacturer's item number | AL 355 D4 F4 01 CFG |
| Article number | 65170348 |
Specifications
| Category code | 35 |
| Housing material | Steel |
| Air volume, unloaded | 5750 m³/h |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Direct-current motor | No |
| Indirect drive | No |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Max. air temperature | 60 °C |
| 2-speed motor | No |
| Suitable for electronic control | Yes |
| Suitable for frequency control | Yes |
| Suitable for low-current control | No |
| Suitable for transformer control | No |
| Pole-reversible | No |
| Length | 383 mm |
| Duct diameter | 355 mm |
| Connection | Insert end |
