Axial 355 mm Duct Fan Flue Gas F300 – AL 355 D2 F3 02 CFG
The AL 355 D2 F3 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, certified for flue gas discharge according to the F300 standard. By employing the latest numerical design techniques, the system efficiency has been significantly improved and the operating range has been broadened. Thanks to adjustable blades, this fan is versatile and particularly suitable for both daily ventilation and smoke and heat extraction in emergency situations (dual-use).
Robust Design with Optimized Weight
The fan is designed with a robust yet lightweight construction, ensuring easy installation and efficient handling. It is equipped with an IEC standard motor suitable for frequency control. The aerodynamically optimized blades contribute to increased system efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C and meets the F300 specification for flue gas ventilation. The fan is supplied without a terminal box but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With more than 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321404 |
| Manufacturer's item number | AL 355 D2 F3 02 CFG |
| Article number | 65170355 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 6390 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 355 mm |
