Axial 355 mm Duct Fan – AL 355 D42U 02 CFG
The AL 355 D42U 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. By utilizing the latest numerical design techniques, the system efficiency has been significantly improved and the operating range has been greatly expanded. Thanks to the adjustable blades, this fan is versatile and ideal for various ventilation needs in commercial and industrial environments.
Robust Design with Optimized Weight
This fan is designed with an optimized, lightweight construction that allows for easy installation and efficient handling. Equipped with an energy-efficient IE3 motor, which is 2-stage adjustable via a Dahlander connection for flexible control and energy savings. The aerodynamically optimized blades ensure increased system efficiency. The model is suitable for continuous operation at air temperatures up to 60 °C. The fan is supplied without a terminal box, but with a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With more than 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320773 |
| Manufacturer's item number | AL 355 D42U 02 CFG |
| Article number | 65169967 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 4645 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 355 mm |
