Good points
- Brand: Ruck
- AC motor
- Standard temperature
- Frequency controlled
Axial 355 mm Duct Fan – AL 355 D2 02 CFG
The AL 355 D2 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. By utilizing the latest numerical design techniques, system efficiency has been optimized and the operating range significantly expanded. Thanks to the adjustable blades, this fan is versatile, making it suitable for a wide range of applications in both the commercial and industrial sectors.
Robust Design with Optimized Weight
The fan features a lightweight yet robust construction that simplifies installation and facilitates handling. The optimized design reduces weight without compromising durability. Equipped with an IEC standard motor that can be controlled via a frequency inverter. The aerodynamically optimized blades contribute to increased system efficiency. The fan is suitable for continuous operation at air temperatures up to 60 °C. This model is supplied without a terminal box but comes with a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product that meets the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320759 |
| Manufacturer's item number | AL 355 D2 02 CFG |
| Article number | 65169960 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 6390 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 355 mm |
