Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 315 mm Duct Fan Flue Gas F400 – AL 315 D4 F4 01 CFG
The AL 315 D4 F4 01 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, specifically for flue gas exhaust according to the F400 standard. By applying the latest numerical design techniques, system efficiency has been significantly improved and the operating range expanded. The adjustable blades ensure optimal adaptation to various applications, both for standard ventilation and smoke and heat exhaust in case of fire (dual-use).
Robust Design with Optimized Weight
The smart, lightweight design makes this fan easy to install and handle efficiently. Equipped with an IE3 motor that is 2-stage adjustable via a Dahlander connection, allowing for flexible control and energy savings. The aerodynamically shaped blades contribute to increased system efficiency. The fan is designed for continuous operation at air temperatures up to 60 °C and meets the F400 specification for flue gas ventilation. Delivered without a terminal box, but with a cable for easy connection of an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With more than 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321329 |
| Manufacturer's item number | AL 315 D4 F4 01 CFG |
| Article number | 65170314 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 4980 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 315 mm |
