- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 315 mm Duct Fan Flue Gas F300 – AL 315 D42U F3 02 CFG
The AL 315 D42U F3 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, suitable for flue gas discharge in accordance with the F300 standard. Thanks to advanced numerical design techniques, the system efficiency has been increased and the operating range has been broadened. The adjustable blades provide maximum flexibility, making this fan ideal for both daily ventilation and smoke and heat extraction during a fire (dual-use).
Robust Design with Optimized Weight
This fan is designed with an optimized, lightweight construction that allows for easy installation and efficient handling. Equipped with an IE3 motor that is 2-stage adjustable via a Dahlander connection, for flexible control and energy savings. The aerodynamically shaped blades significantly improve system efficiency. Suitable for continuous operation at air temperatures up to 60 °C and certified for flue gas discharge in accordance with the F300 standard. The fan is supplied without a terminal box, but with a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321596 |
| Manufacturer's item number | AL 315 D42U F3 02 CFG |
| Article number | 65170500 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 5620 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 315 mm |
