Axial 315 mm Duct Fan Flue Gas F300 – AL 315 D2 F3 03 CFG
The AL 315 D2 F3 03 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, specifically for flue gas discharge in accordance with the F300 standard. Thanks to the application of the latest numerical design techniques, system efficiency has been significantly improved and the operating range has been expanded. With adjustable blades, the fan is versatile and suitable for both regular ventilation and smoke and heat extraction in case of fire (dual-use).
Robust Design with Optimized Weight
This fan combines a sturdy design with optimized weight, ensuring easy installation and efficient handling. Equipped with an IEC standard motor suitable for frequency control. The aerodynamically optimized blades contribute to increased system efficiency. The AL 315 D2 F3 03 CFG is designed for continuous operation at air temperatures up to 60 °C and operates reliably according to the F300 specification in case of fire. The model is supplied without a terminal box but includes a cable for easy connection of an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With more than 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321589 |
| Manufacturer's item number | AL 315 D2 F3 03 CFG |
| Article number | 65170497 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 6155 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 315 mm |
