Axial 315 mm Duct Fan – AL 315 D42U 02 CFG
The AL 315 D42U 02 CFG from Ruck is an innovative, energy-efficient axial fan designed for medium pressure applications. By utilizing the latest numerical design techniques, system efficiency has been significantly improved and the operating range has been broadened. Thanks to the adjustable blades, this fan is versatile for various ventilation applications. It is ideal for situations where both efficiency and reliability are paramount.
Robust Design with Optimized Weight
This fan combines a robust construction with an optimized, lightweight design for easy installation and handling. The fan is equipped with a high-quality IE3 motor and is 2-stage adjustable via a Dahlander switch, ensuring efficient control and energy savings. The aerodynamically designed blades provide increased efficiency. This model is suitable for continuous operation at air temperatures up to 60 °C. It is supplied without a terminal box but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product that meets the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320742 |
| Manufacturer's item number | AL 315 D42U 02 CFG |
| Article number | 65169915 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 5620 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 315 mm |
