Axial 315 mm Duct Fan – AL 315 D4 01 CFG
The AL 315 D4 01 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. By utilizing the latest numerical design techniques, system efficiency has been significantly improved and the operating range has been broadened. Thanks to the adjustable blades, the fan is versatile for various ventilation applications in both residential and industrial environments.
Robust Design with Optimized Weight
This fan is designed with ease of installation and durability in mind. The optimized design results in a lower weight without compromising robustness. It is equipped with an IEC standard motor that can be controlled via a frequency inverter. The aerodynamically shaped blades contribute to increased efficiency of the overall system. The fan is suitable for continuous operation at air temperatures up to 60 °C. The model is supplied without a terminal box, but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544320728 |
| Manufacturer's item number | AL 315 D4 01 CFG |
| Article number | 65169908 |
Specifications
| Category code | 35 |
| Length | 383 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 4980 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 315 mm |
