Axial 1250 mm Duct Fan Flue Gas F400 – AL 1250 D6 F4 04 CFG
The AL 1250 D6 F4 04 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications, specifically for flue gas extraction in accordance with the F400 standard. Thanks to advanced numerical design techniques, system efficiency has been significantly enhanced. The adjustable blades provide a wide operating range, making the fan optimally suitable for both regular ventilation and smoke and heat extraction in emergency situations.
Robust Design with Optimized Weight
This fan features a lightweight yet robust design that allows for easy installation and efficient handling. The optimized design has reduced the weight without compromising durability. The fan is equipped with an IEC standard motor and is suitable for frequency control. The aerodynamically optimized blades contribute to increased system efficiency. Designed for dual-use applications, this model operates reliably at air temperatures up to 60 °C and meets the F400 specification for flue gas ventilation. The fan is supplied without a terminal box but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322159 |
| Manufacturer's item number | AL 1250 D6 F4 04 CFG |
| Article number | 65170858 |
Specifications
| Category code | 35 |
| Length | 728 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 115073 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 1250 mm |
