Axial 1250 mm Duct Fan Flue Gas F300 – AL 1250 D6 F3 06 CFG
The AL 1250 D6 F3 06 CFG from Ruck is an innovative, energy-efficient axial fan designed for medium pressure applications, certified for flue gas discharge according to F300 standards. By applying the latest numerical methods, system efficiency has been significantly improved. The adjustable blades provide a wide operating range, making this fan versatile for various environments. The AL 1250 D6 F3 06 CFG is suitable for both regular ventilation and flue gas and heat discharge in emergencies.
Robust Design with Optimized Weight
This axial fan is designed with ease of use and durability in mind. Thanks to the optimized design, the weight has been reduced, ensuring easy installation and handling. The fan is equipped with an IEC standard motor suitable for frequency control. Aerodynamically optimized blades enhance overall system efficiency. The fan is designed for dual-use applications and operates reliably at a continuous air temperature of up to 60 °C. In case of fire, this fan complies with the F300 standard. The model is supplied without a terminal box but includes a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With over 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322111 |
| Manufacturer's item number | AL 1250 D6 F3 06 CFG |
| Article number | 65170844 |
Specifications
| Category code | 35 |
| Length | 728 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 138000 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 1250 mm |
