Axial 1250 mm Duct Fan – AL 1250 D6 04 CFG
The AL 1250 D6 04 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. Thanks to the application of the latest numerical methods, both the efficiency and the operating range have been significantly improved. The fan features adjustable blades, providing a wide range of applications. This model is particularly suitable for situations where high air output and reliable performance are desired, such as in parking garages, industrial environments, and large ventilation systems.
Robust Design with Optimized Weight
The axial fan has a thoughtful, lightweight design for easy installation and better handling. The optimized product design has reduced the weight without compromising on quality and durability. It is equipped with an IEC standard motor that can be controlled via frequency converters. The aerodynamically optimized blades significantly increase system efficiency. This fan is suitable for continuous operation at air temperatures up to 60 °C. The model is supplied without a terminal box and comes with a cable for easy connection to an external switch.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German company with years of experience. They are market leaders in the field of axial fans. With more than 300 dedicated employees, they work daily on new developments and technologies. The company ensures quality assurance to deliver an excellent product in accordance with the latest ERP (Energy Related Product) requirements.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544321299 |
| Manufacturer's item number | AL 1250 D6 04 CFG |
| Article number | 65170294 |
Specifications
| Category code | 35 |
| Length | 728 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 115073 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 1250 mm |
