Good points
- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 1000 mm Duct Fan Flue Gas F300 – AL 1000 D84U F3 03 CFG
The AL 1000 D84U F3 03 CFG from Ruck is an innovative and energy-efficient axial fan, designed for both flue gas discharge and daily ventilation. Utilizing the latest numerical methods, the design has been optimized for maximum system efficiency. Thanks to the adjustable blade positions, this model has a wide operating range and is suitable for various applications. The fan is certified as an F300 flue gas fan and is suitable for continuous use up to 60 °C, making it an excellent dual-use solution: for daily air exchange and flue gas heat discharge during a fire.
Robust Design with Optimized Weight
The AL 1000 D84U F3 03 CFG is designed with a sturdy yet lightweight construction, ensuring easy installation and efficient maintenance. The optimized design has reduced the weight without compromising performance or reliability. The fan is equipped with an energy-efficient IE3 motor with two-speed control via a Dahlander switch. This allows for flexible and economical operation. The specially shaped rotor and stator blades deliver high efficiency in medium-pressure applications. Ideal for use in larger commercial and industrial ventilation systems.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in ventilation technology. With a team of over 300 specialists, they develop high-quality fans for various applications daily, with a strong focus on energy efficiency and fire safety. The products comply with current ERP guidelines and the strictest quality standards. With a fan from the AL series, you are guaranteed reliable technology.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322623 |
| Manufacturer's item number | AL 1000 D84U F3 03 CFG |
| Article number | 65171207 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 72895 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 1000 mm |
