Axial 1000 mm Duct Fan Flue Gas F300 – AL 1000 D84U F3 02 CFG
The AL 1000 D84U F3 02 CFG from Ruck is an innovative and high-efficiency axial fan, designed for both flue gas extraction and daily ventilation. Utilizing advanced numerical simulation methods, this fan has been optimized for maximum system efficiency. The adjustable blade angles provide a wide operating range, making this model suitable for various applications. As an F300-certified flue gas fan, it is suitable for continuous operation up to 60 °C and ideal for dual-use: regular air exchange and flue gas heat removal in case of fire.
Robust Design with Optimized Weight
The AL 1000 D84U F3 02 CFG is designed with a solid yet lightweight construction, facilitating installation and maintenance. The product design has been optimized with weight reduction as a key focus, without compromising performance or robustness. The fan is equipped with an energy-efficient IE3 motor with two-speed control via a Dahlander connection, allowing for flexible and economical operation. Thanks to aerodynamically shaped rotor and stator blades, this model delivers excellent performance in medium-pressure applications. Ideal for larger commercial and industrial ventilation projects.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with a strong reputation in ventilation technology. With over 300 employees, they develop high-quality solutions daily that meet the strictest standards for energy efficiency and fire safety. Products from the AL series, such as this D84U F3 02 CFG, comply with current ERP guidelines and are designed for reliable performance in demanding situations.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322616 |
| Manufacturer's item number | AL 1000 D84U F3 02 CFG |
| Article number | 65171204 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 63390 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 1000 mm |
